Model-concept of the reconstruction of hospital No. 20 named after I.S. Berzon

WORK SAMPLES

SITUATION:
The customer has won the tender and is developing a preliminary design for the reconstruction of the Krasnoyarsk Interdistrict Clinical Hospital No. 20 named after I.S. Berzon. As part of the work there is a presentation model.

TASK:
To make a model considering technical specifications of the tender.

SOLUTION:
Mobile conceptual architectural model of a hospital complex in 1:1000 scale.

For us, this story began a long time ago - in 2020, Ministry of Health contact us to consult them regarding technical specifications for the model. Having found out the needs of the customer, we formulated what life the product will have. The model should be at meetings and presentations, so we described it as mobile, suitable for transportation in a car, stylish, conceptual, allowing you to see the project, without being distracted by the details.

The new volume of buildings in the complex structure of the buildings of the 20th hospital was decided to show in the following way: all old buildings were made of wood, and the new volumes and transitions were made of a transparent luminous material. This allows you to read the idea of architects, without getting confused in endless buildings and transitions.

Later, the customer won the tender and turned to us to make a model in accordance with the technical specification. After going through a series of selection procedures, we won the competition and started manufacturing.

The buildings of the main campus should be cast in resin. Master models of the main campus were printed by segments, then assembled. We made the main relief using 3D shaping operation.

Final result is on the photo. The model is equipped with a pedestal-base with a luminous logo of the customer. The pedestal consists of four plane tables which and can be assembled in just a minute.
